Zigzag Sewing Machine.

본문

Product Contact

아래 양식에 내용을 입력하시어 전송하시면 최대한 신속히 연락드리도록 하겠습니다.

Product Description

 MODEL CODE












 DETAILED INFORMATION










 SPECIFICATION


MODEL ST-1452/3 ST-2452/3
Application Medium Heavy Materials Heavy Materials
Stitch Form Lock Stitch 1-Needle Lock Stitch 2-Needle
Neeedle DP x 5 (#14~#23) DP x 5 (#14~#23)
Maximum sewing speed 2,000 spm 2,000 spm
Maximum Stitch length 8.0 mm 8.0 mm
Maximum Zigzag Width 8.0 mm 8.0 mm
Lift of the Presser Foot (Manual) 7.0 mm 7.0 mm
Thread Take-up Stroke 67.0 mm 67.0 mm
Needle Bar Stroke 33.8 mm 33.8 mm
Feed type Bottom Feed Upper & Lower Feed
Hook Type Rotary Hook Rotary Hook
Direction Vertical Vertical
Lubrication System Automatic-Lubrication Automatic-Lubrication
Auto Trimmer X X
Automatic Backtacking  X X
Automatic Up Foot Lifter X X
Needle Up-Down O (Saving Motor) / X (Clutch Motor) O (Saving Motor) / X (Clutch Motor)
Motor Saving Motor / Clutch Motor Saving Motor / Clutch Motor
Power Single phase 220V Single phase 220V
