ST-2510／2520 ST-2510 / 2520
HIGH SPEED, 1-NEEDLE, DIRECT-DRIVE SEWING MACHINE
- with AUTOMATIC THREAD TRIMMER
Product Contact
아래 양식에 내용을 입력하시어 전송하시면 최대한 신속히 연락드리도록 하겠습니다.
Product Description
■ MODEL CODE
|
■ DETAILED INFORMATION
■ SPECIFICATION
| MODEL | ST-2510A | ST-2520A | ST-2520A-7 | ST-2510B | ST-2520B | ST-2520BS | |
| Application | Thin~Medium Heavy Materials | Heavy Materials | |||||
| Stitch Form | Lock Stitch 1-Needle | Lock Stitch 1-Needle | Lock Stitch 1-Needle | Lock Stitch 1-Needle | Lock Stitch 1-Needle | Lock Stitch 1-Needle | |
| Neeedle | DB x 1 (#9~#18) | DB x 1 (#9~#18) | DB x 1 (#9~#18) | DB x 1 (#19~#23) | DB x 1 (#19~#23) | DB x 1 (#19~#23) | |
| Maximum sewing speed | 4,000 spm | 4,000 spm | 4,000 spm | 4,000 spm | 4,000 spm | 4,000 spm | |
| Maximum Stitch length | 5.0 mm | 5.0 mm | 5.0 mm | 7.0 mm | 7.0 mm | 7.0 mm | |
| Lift of the Presser Foot (Manual) | 13.0 mm | 13.0 mm | 13.0 mm | 13.0 mm | 13.0 mm | 13.0 mm | |
| Thread Take-up Stroke | 58.9 mm | 58.9 mm | 58.9 mm | 58.9 mm | 58.9 mm | 58.9 mm | |
| Needle Bar Stroke | 30.7 mm | 30.7 mm | 30.7 mm | 30.7 mm | 30.7 mm | 30.7 mm | |
| Hook | Type | Rotary Hook | Rotary Hook | Rotary Hook | Rotary Hook | Rotary Hook | Rotary Hook |
| Direction | Vertical | Vertical | Vertical | Vertical | Vertical | Vertical | |
| Lubrication System | Automatic-Lubrication | Automatic-Lubrication | Automatic-Lubrication | Automatic-Lubrication | Automatic-Lubrication | Automatic-Lubrication | |
| Auto Trimmer | X | O | O | X | O | O | |
| Automatic Backtacking | X | O | O | X | O | O | |
| Automatic Up Foot Lifter | X | O | O | X | O | X | |
| Needle Up-Down | O | O | O | O | O | O | |
| Motor | Direct Motor | Direct Motor | Direct Motor | Direct Motor | Direct Motor | Direct Motor | |
| Power | Single phase 220V | Single phase 220V | Single phase 220V | Single phase 220V | Single phase 220V | Single phase 220V | |
