ST-797BLD ST-797BLD
TWIN NEEDLE, NEEDLE FEED, SPLIT NEEDLE BAR SEWING MACHINE, 2X HOOK
- with AUTOMATIC THREAD TRIMMER
Product Contact
아래 양식에 내용을 입력하시어 전송하시면 최대한 신속히 연락드리도록 하겠습니다.
Product Description
■ MODEL CODE
|
■ DETAILED INFORMATION
■ SPECIFICATION
| MODEL | ST-797BLD | ST-797BLD-7 | |
| Application | Medium Heavy Materials | Medium Heavy Materials | |
| Stitch Form | Lock Stitch 2-Needle | Lock Stitch 2-Needle | |
| Neeedle | DP x 5 (#14~#23) | DP x 5 (#14~#23) | |
| Maximum sewing speed | 3,000 spm | 3,000 spm | |
| Maximum Stitch length | 5.0 mm | 5.0 mm | |
| Lift of the Presser Foot | Manual | 7.0 mm | 7.0 mm |
| Auto | - | 15.0 mm | |
| Thread Take-up Stroke | 67.0 mm | 67.0 mm | |
| Needle Bar Stroke | 33.8 mm | 33.8 mm | |
| Hook | Type | Rotary Hook | Rotary Hook |
| Direction | Horizonal | Horizonal | |
| Lubrication System | Automatic-Lubrication | Automatic-Lubrication | |
| Auto Trimmer | X | O | |
| Automatic Backtacking | X | O | |
| Automatic Up Foot Lifter | X | X | |
| Needle Up-Down | O | O | |
| Motor | Direct Motor | Direct Motor | |
| Power | Single phase 220V | Single phase 220V | |
